Lucy Electric Street Lighting Cut Outs
from only £15.70 Ex VAT
Manufactured by Lucy Electric
These popular products have many class leading features providing DNO primary and secondary isolation with extension boxes suitable for tails SWA and concentric cable and are also able to control festive lighting units.
Supplied to Jointing Tech by industry leaders Lucy Electric, is a range of proven street lighting cut outs featuring Zodion fused Titan and Trojan cutouts and isolators.
With its low body split line to maximise cabling access, the SLF is the simplest exponent of the single pole street lighting cut outs.
Made using high quality, resilient, engineering grade thermoplastics and fully electroplated brass components for longevity and reliability on site means the SLF has been proven to have a long service life even in the most demanding locations.
With safety being of paramount importance the effortlessly operated cam operated fuse handle ensures that electrical disconnection takes place in one movement prior to the fuse carrier being extracted.
- Single Pole isolation
- Single fuse
- Hex head screws
- Clear lower cover for visibility of cable shrink-back
Electroplated brass terminals with serrated bores Maximum cable size; 16mm2 stranded copper or 25mm2 solid aluminium conductors Cable entry via PVC grommets as standard Outgoing cables exit below horizontal to form drip loop Sealing wire facility Options
Designed and tested in accordance with BS 7654:1997 25A maximum fuse rating Accepts fuse links to BS 88 Part 1, AC 16 tag type
IP22 rating
BS7654 Type 1 (SNE)
BS7654 Type 2 (CNE)
