33kV Single Core Armoured XLPE Inline Heat Shrink Joint


from only £498.75 Ex VAT

Tyco Inline heat shrink joints for single core aluminium wire armoured XLPE cables

Designed to join inline single core 33kV aluminium wire armoured XLPE cables

  • Highly reliable U.K. industry standard joint
  • Will accommodate a mechanical or crimp connector
  • Quick installation time
  • Can be used for a size transition joint with the aid of mechanical connectors
  • Unlimited shelf life - simplifying the logistics management procedure and reducing costs
  • No special tools required for installation
  • Kit contents - Void filling tapes, stress control and insulation tubing, wire armour continuity, inner and outer sealing sleeve
  • Inline heat shrink joints for single core aluminium wire armoured XLPE cables
  • A range of medium voltage heat shrink joints are in stock and available for next day delivery throughout the UK

*EXCLUDES CONNECTORS*

Just part of an extensive range of medium voltage (MV) inline heat shrink cable joints available from Jointing Tech.





Technical Data
  • Tested in accordance with CENELEC specification HD 629 or IEC 60502-4 for joints
Order
Part Number Wolseley Code Conductor Size Price Ex VAT Quantity
SXAW-6132 CJ3167 120-240mm² £498.75
SXAW-6142 CJ2718 300-630mm² £787.50
