  • Disconnecting Link - Single
  • Disconnecting Link - Single

Disconnecting Link - Single

from only POA

Furse Earth Bars – Single Disconnecting Link  (Bare Copper & Tinned Copper Options available)

Earth Bars are an efficient and convenient way of providing a common earth point with integral disconnecting links which facilitate easy isolation for testing purposes

  • An earth bar with single disconnecting link to facilitate multiple connections to earth with the option of isolating for testing purposes
  • Manufactured out of high conductivity 50x6mm HD copper bar
  • The PVC channel base is entirely corrosion proof - made with high impact UPVC unlike the traditional galvanised steel channel
  • Lighter and easier to handle - the use of a modern polymer channel has reduced the weight of the product making it easier to handle
  • No need for insulators - spacers used as the PVC base is insulating
  • M10 phosphor bronze stud assemblies
  • Pre-drilled holes for ease of installation
  • A range of four designs to meet most installation requirements
  • Custom made earth bar service available
  • Tinned options available on request
Datasheets
Order
Part Number Wolseley Code Stud Material No. of Ways Stud Size Weight Each Price Ex VAT Quantity
LK243-4 CJ2115 4 M10 375 x 90 x 96mm 1.9kg EBC104 POA
LK243-6 CJ3199 6 M10 475 x 90 x 96mm 2.30kg EBC106 £83.05
LK243-6SS 6 M10 475 x 90 x 96mm 2.30kg STAINLESS STEEL (ECONOMY PRODUCT) £64.58
LK243-8 CJ2099 8 M10 575 x 90 x 96mm 2.70kg EBC108 £95.03
LK243-8SS 8 M10 575 x 90 x 96mm 2.70kg STAINLESS STEEL (ECONOMY PRODUCT £75.60
LK243-10 CJ2107 10 M10 725 x 90 x 96mm 3.30kg EBC110 £115.50
LK243-10SS 10 M10 725 x 90 x 96mm 3.30kg STAINLESS STEEL (ECONOMY PRODUCT £89.25
LK243-12 CJ2105 12 M10 825 x 90 x 96mm 3.70kg EBC112 £130.73
LK243-12SS 12 M10 825 x 90 x 96mm 3.70kg STAINLESS STEEL (ECONOMY PRODUCT) £104.21
LK243-14 14 M10 925 x 90 x 96mm 4.10kg Phosphor Bronze POA
LK243-16 CJ2131 16 M10 1025 x 90 x 96mm 4.50kg EBC116 POA
LK243-18 CC5185 18 M10 1125x90x96mm 4.90kg Phosphor Bronze POA
LK243-20 20 M10 1275 x 90 x 96mm 5.50kg EBC120 POA
LK243-22 22 M10 1375 x 90 x 96mm 5.90kg Phosphor Bronze POA
LK243-24 24 M10 1475 x 90 x 96mm 6.30kg EBC124 POA
LK243-26 26 M10 1575 x 90 x 96mm 5.70kg Phosphor Bronze POA
LK243-28 28 M10 1725 x 90 x 96mm 7.40kg Phosphor Bronze POA
LK243-30 30 M10 1825 x 90 x 96mm 7.80kg Phosphor Bronze POA
